Product Features:
- MID B&D Approved - 0120/SGS0198
- Single Phase (1P2W)
- Displays Total Active Energy (kWh) and Partial Resttable Energy (kWh).
- 100A AC
- 230V
- Dual Pulse Outputs
- 2-DIN Module
- Digital Backlit Display
SDM230DR is a basic digital single-phase kWh energy meter, which measures up to 100A direct load. The unit measures Total Active Energy and Partial Resttable Energy (kWh). This meter is very popular due to its cost-effectiveness and simplicity of installation. This Series has been assessed and certified as meeting the requirements of EC Directive 2004/22/EC. The EC Type Examination Certificate Number is 0120/SGS0206.
