M3N1-45 Three Phase Current Transformer (250-600A) /5A

SKU: M3N1-45

£35.50

Excluding VAT. Shipping calculated at checkout.

Product Features:

  • 30.5mm x 30.5mm Aperture
  • 250-600A Primary Current
  • 5A Secondary Current
  • Secondary M4 Screw Terminals
  • Accuracy Class 0.5, 1 or 3
  • Busbar or DIN Rail Mounted

The M3N1 Range of 3-in-1 Current Transformers from Crompton Instruments combines three traditional Current Transformers into one molded case. These can be directly installed in line with a three-phase molded case circuit breaker, saving installation time and taking up less space than three individual CTs. The M3N1-45 is ideal for applications such as Distribution systems, Generator sets, Control Panels and Switchgear.
